Aleko Single Swing Gate Operator - GG650/AS650 AC/DC - Solar Kit 60W

ALEKO^®GG650/AS650 Single Swing Gate Operator is designed for residential/commercial applications. Stay warm and dry in your vehicle. This Single Swing Opener will handle single swinging gate up to 10 ft in length and weighing up to 650 lb. ALEKO^® GG650/AS650 has powerful 24VDC motor, which provide exceptional starting torque and feature soft start/stop operation. This promotes longer gate and operator life, as well as dependable performance.

No power? No problem!

Features

• Access your gates through remote control or keypad
• Smooth and soft start and stop function
• Emergency Release key in case of power failure
• Dual/Single gate running mode
• Optional master and slave gate running
• Adjustable opening/closing interval between master and slave gate
• Stop/Reverse in case of obstruction during gate opening/closing
• The force of the motor can be programmed
• Optional photocell protection (not included)
• Built in adjustable auto-close (programmable from 0-99 sec)
• Digital display indicates the running situation and setting menu
• Reliable electromagnetic limit switches improve adjustment of the 'open' and 'close' position
• Motor: 24V DC, 80W per actuator, 3A current
• Power supply: 110V/60Hz (220V/50Hz - not included)
• Actuator speed: 1.6 cm/second (5/8 inch/second)
• Actuator travel: 385mm (15 3/4 inches)
• Max Weight of each gate panel: 300 kg (650 lb)
• Max Width of each gate panel: 3 m (10ft)
• H Bracket Dimensions for 30W Solar Panel (LxW): 15.35 x 9.6 inches
• L Bracket Dimensions (LxW): 5.3 x 1.9 inches
• Auto-closing duration: programmable (from 0 to 99 seconds)
• Ambient temperature: -22C(-4F) ~ +55C(+122F)
